15.6 Inch PoE NFC Wall-Mounted Android Advertising Display
Designed for modern commercial interiors, this 15.6-inch wall-mounted Android display combines a clean natural wood frame with reliable commercial performance, making it well suited for retail stores, hotel lobbies, elevators, and smart office spaces. The Full HD IPS screen delivers clear visuals and wide viewing angles, while the Android 14 system powered by the RK3568 quad-core processor ensures smooth operation for daily content playback and interactive applications. Optional capacitive touch enables intuitive user interaction when needed, and flexible connectivity options support easy integration into existing networks and systems. With support for high-quality media playback and customization of logo, content, and installation methods, the display offers a practical and adaptable solution for digital signage, smart retail environments, meeting rooms, and elevator advertising projects.
- Video
- Features
- Parameter
- Products Description
- Packaging
- Recommended Products
Video
Features
- CPU:RK3568
- RAM:4 GB
- Memory:32 GB
- System:Android 14
- Panel: 15.6 Inch LCD Panel
- Resolution: 1920x1080
- Support NFC/RFID POE
- Wooden-frame
Tablet Key Features
Parameter
| System | CPU | RK3568 Quad core cortex A55 | |
| RAM | 4GB | ||
| Internal memory | 32GB | ||
| Operation system | Android 14 | ||
| Display | Panel Size | 15.6" | |
| Panel Type | IPS | ||
| Resolution | 1920*1080 | ||
| Display Colors | 16.7M | ||
| Color Gamut | 45% NTSC | ||
| Viewing angle | R/L 85/85, U/D 85/85 | ||
| Display mode | Normally black | ||
| Contrast ratio | 700:1 | ||
| Response Time | 30ms | ||
| Back-light Type | ELed | ||
| Luminance | 300cd/m2 | ||
| Aspect Ratio | ,16：9 | ||
| Touch | Model Type | Capacitive touch screen | |
| Number of points | 10-Point | ||
| Interface for touch | I2C | ||
| Network | WiFi | IEEE 802.11b/g/n/a/ac | |
| Bluetooth | Bluetooth 5.4 | ||
| Ethernet | 10M/100M/1000M | ||
| Interface | RJ45 | Ethernet interface | |
| USB | USB 2.0 HOST | ||
| USB | USB 3.0 HOST | ||
| Type-C | Full Function ( Except for charging function ) | ||
| HDMI IN | Support 800*600,1024*768,1280*720,1280*800,1280*1024,1366*768,1600*900,1920*1080,3840*2160, etc | ||
| Power Jack | DC power input | ||
| Media plays | Video format | MPEG-1,MPEG-2,MPEG-4,H.265,H.264,H.263,VC-1,VP8,VP9,MVC,AV1, etc., support up to 4K | |
| Audio format | MP3/WMA/AAC/WAV/OGG, etc | ||
| Photo | JPEG/PNG/GIF,etc | ||
| Other | Product Colors | White | |
| Outer frame | Wooden-frame | ||
| Outer frame color | Black/White/Wood Grain | ||
| VESA | 75mm*75mm | ||
| Button | Power/Vol+/Vol- | ||
| G-sensor | Support | ||
| NFC | Optional , 13.56MHz，ISO/IEC 18092, ISO/IEC 21481, ISO/IEC 14443 A&B, ISO/IEC 15693, Japanese Industrial Standard (JIS) (X) 6319-4, MIFARE Classic encrypted tags and cards | ||
| Speaker | 4Ω*3W*2 | ||
| Language | Multi-language | ||
| Certificates | CCC/CE/FCC,Google EDLA | ||
| POE | Optional （IEEE802.3at, up to 30W ) | ||
Products Description
The 15.6-inch display offers the perfect balance between size and functionality—large enough to deliver impactful visuals with Full HD 1920×1080 resolution, yet compact enough for easy wall mounting and space-saving installation. Its moderate size makes it ideal for use in elevators, retail shelves, hotel corridors, and office entrances. With high pixel density, it ensures sharp, vibrant images, while its lightweight design reduces transportation and installation costs. When combined with touch functionality, it also provides an intuitive and comfortable user interaction experience at close range.
Powered by the RK3568 quad-core Cortex-A55 processor, this display delivers a balanced combination of performance and long-term stability for commercial use. With 4GB RAM and 32GB internal storage, it handles multimedia playback, application loading, and system operations smoothly, even during continuous operation. The performance design is optimized for professional scenarios such as digital signage, information kiosks, and interactive terminals, helping integrators and project owners achieve reliable user experiences while reducing maintenance and operational complexity over time.
Running on Android 14, the system offers a familiar and flexible operating environment that is easy to deploy, manage, and update. The open Android ecosystem supports a wide range of commercial applications, CMS platforms, and third-party software, allowing projects to scale without complex development. Daily operation remains intuitive for end users, while background management stays efficient for IT teams, making the display well suited for long-term commercial deployment in digital signage, information release, and interactive applications.
The responsive touch screen provides a simple and intuitive interaction experience, allowing users to navigate content naturally with light taps and gestures. Smooth touch performance ensures fast response without lag, making daily operation comfortable for users of different age groups. Designed for commercial environments, the stable touch system supports frequent interaction in applications such as information inquiry, self-service guidance, and interactive advertising, helping improve user engagement while maintaining reliable performance over long-term use.
In stand-alone mode, the display supports direct content playback through a USB drive or SD card, automatically recognizing and playing media files without network connection or complex configuration. This plug-and-play capability simplifies deployment in locations where centralized control is not required, making it a practical choice for retail promotions, public information displays, and temporary installations while ensuring stable and reliable operation.
Packaging
Packaging support customization, users can customize logo tags on the box. Customized packaging can be customized according to the different needs of the user.
